Jaguar X250 XF Grey/Polished 6 Spoke 17 inch Alloy Wheels, 07-11
This is a set of 4 wheels for the Jaguar XF 07-11.
These wheels are supplied with the required hardware to fit them to the car.
Tyres are not included.
They are a 17 inch by 7.5 inch wheel (17 x 7.5) and are ideally suited to tyres in the 215 to 235 width range. These are common tyre sizes and therefore there is a wide range of tyres available from budget to slick options.
These have an offset when fitted with the supplied hardware of ET23. This means that they have around 22mm of poke over the standard wheels for the car.
Prior to ordering, please check you have the required arch clearance. If not, you will need to modify the arches for a safe fitment.
Product Fitment Data:
Additional Poke – 22mm
Wheel Spacer Included? – Yes – 15mm
Stud Conversion? – No
Wheel Offset When Fitted – ET23
Wheel Nuts – 17mm – Black
Vehicle Fitment Data:
Make – Jaguar
Model – XF
Chassis Code – X250
Production Years – 07-11
Hub PCD – 5 x 108
Hub Bolt/Stud Thread – M12 x 1.5
OE Offset – ET45
Spigot – 63.4mm
Notes – n/a
Wheel Data:
Colour – Grey/Polished
Style – 6 Spoke
Material – Aluminium
Construction – One Piece
Diameter – 17
Width – 7.5
Wheel PCD – 5 x 114.3
Offset – 38ET
Pocketed – Yes
Barbarian Racing BDW Wheels
The Barbarian Racing wheels are only available in a 5 x 114.3 PCD which means less options to hold in stock and greater availability. If your car doesn’t use a 5 x 114.3 PCD then a hub adapter will be supplied. The details of any spacer can be found above along with the theoretical PCD which is what we have used to calculate the extra poke once fitted. Should you damage a wheel/s then replacements are available as singles.
Fitment considerations
Arch clearance – Our calculations are done from OE wheel fitment data which does not indicate the distance the wheel arch is from the hub. Before buying, be sure to measure your arch clearance and if in doubt, contact us prior to purchase.
Brake clearance – Brake caliper size data is not available and therefore we cannot confirm if the wheel will clear the caliper. If these wheels are the same size or larger than what is currently on the car, you will likely have no cause for concern here. If however, you are downsizing the wheels, it’s important to check clearance.
| Weight | 35 kg |
|---|---|
| Dimensions | 60 × 60 × 95 cm |
| Product Video | https://youtu.be/BnfJ8TVs_UA |
| PCD Conversion | Yes to 5 x 114.3 |
| Clearance Information | See the description for details on checking arch and caliper clearance |
| EAN | |
| Package Quantity | 4 |
| Wheel Nuts | 17mm – Black |
| Extra Poke Over OE Wheel (mm) | 22 |
| Fitted Offset (ET) | 23 |
| Notes | n/a |
| Production Years | |
| Chassis Code | X250 |
| Model | XF |
| Manufacturer | Jaguar |
| Brand | |
| Wheel Spacer Included | Yes – 15mm |
| Colour | |
| Stud Conversion? | No |
| Spigot | |
| Stud Diameter | 108 |
| Number of Studs | 5 |
| Car Side PCD | 5 x 108 |
| Rim Offset ET | 38 |
| Rim Width | 7.5 |
| Wheel Diameter | 17 |
| Construction | One Piece |
| Wheel Weight (Kg) | 8.6 |
| Material | |
| Wheel Style | 6 Spoke |
| Finish | Gloss & Polished |
| Country/Region of Manufacture | China |
